Automatic Bollards Retractable Bollards Parking Bollards Hydraulic Bollards
The automatic rising security bollards are strong enough that most vehicles couldn't just drive through them, at least not without substantial damage. But let pedestrians and cyclists, perhaps even motorcycles, pass through easily. The automatic hydraulic bollards is an electric-hydraulic-mechanically operated retractable bollard system. The hydraulic bollards system can be quickly and easily operated. It is suitable for both security and access control applications.
The Automatic Rising Bollard is a retractable bollard, hydraulically powered barricade which has a lift height of 600mm.
Automatic Rising Bollards provide automated heavy-duty vehicle access control and protection against ram-raiding. These units bridge the gap between Automatic Barriers
and Road Blockers in terms of security and cost.
Features:
Industrial hydraulic pump drive unit Motor protection
Security lock on cabinet door
Instantly Reversible
LED Traffic Lights
Override Switch
Switched fused supply
Mains indicator lamp
Reinforced hoses for long service life
Long life hydraulic seals
Automatic Bollard diameter: 215mm diameter
Automatic Bollard Lift Height: 600mm
100% duty rating - the Automatic Bollard is designed for continuous and frequent use Automatic Bollard Finish
Stainless Steel finish Automatic Bollard Control Cabinet
Zinc rich powder prime polyester powder coat white.
Finish provides excellent corrosion protection. Automatic Bollard Accessories Included:
Traffic Control Light system.Highly recommended with all rising bollards installations. Automatic Bollard Operating Speed:
Typical speeds of 5-9 seconds* depending on configuration.
* This is subject to a risk assessment to ensure the automatic equipment complies to BS EN 12453
Automatic Bollard Access controls: A wide range of access control systems are available.
Automatic Bollard Safety control systems: Vehicle detector loops, safety photocells and ultra-sonic sensors are available.
Automatic Bollard Foundations
600mm lift Rising Bollard Foundation: 800mm sq x 880mm deep
Note: Power and control wiring ducts to be incorporated into foundations.
Control Cabinet Foundations: 800mm SQ x D:300mm
It is recommended that the rising bollard`s control cabinet is installed within 10metres of the unit. Installation:
Find the installation location of the center, dug a diameter of 60cm deep 70cm deep pits, the bottom of the sand covered with about 10cm, and then placed the bollard with the ground level flush, and then pouring cement around the bollard until the ground.
The use of methods:
Decrease: Use the key to activate and release the mechanism. Apply pressure at the top of the bollard to return the bollard to the ground and bollard will be lock automatically.
Rise: Activated with the key, apply pressure at the top of the bollard untill the pile is raised and locked automatically in the highest position.
Application
The retractable hydraulic bollardr are widely used in urban transport, pedestrian streets, highways, toll stations, airports, schools, banks, large clubs, car parks and many other occasions. Through the restrictions on the passing vehicles, effectively maintain safety of the main facilities and places.
A the government unit of the door
B pedestrian street
C road isolation belt
D multi-purpose square
E open park
F district, banks, schools
G the highway
